Labs

There are several laboratories for various programmes offered at VIT-AP. Each laboratory is well-equipped to serve the requirements of the respective programmes. With state-of-the-art facilities, the laboratories are a place for the students to practise, experiment, and innovate.

Mechanical Engineering

Software Licenses: Solid Work Class Room Pack Edu Edition, Digimat Software
Work Shop Lab:
Equipments:

  • • Bench Grinder
  • • Drill Machine
  • • Press Brake Machine
  • • Lathe Machine
  • • Hydraulic Power Hacksaw
  • • Shearing Machine
  • • Power Press Machine
  • • Surface Grinder
  • • MIG Welding Machine
  • • TIG Welding Machine
  • • Ultrasonic Welding Machine
  • Materials Engineering Lab:
    Equipments:

    • Optical Microscope,
    • • Impact Testing Machine,
    • • Injection Moulding Machine,
    • • Cold Press, Sonicator,
    • • Tensile Testing Machine,
    • • Muffle Furnace
    • • Optical Microscope
    • • Tensile Testing Machine
    • • (Material Testing Machine)
    • • Impact Testing Machine
    • • Motorized notch cutter
    • • Sigma Type Mixer
    • • Universal Hydraulic Press with Hot PLATE
    • • (Compressor Moulding Machine)
    • • Disc Polishing Machine
    • • Rockwell Hardness Tester
    • • Muffle Furnace
    • • Ball Milling Machine
    • • Fume Hood
    • • Heat Distortion Temperature Apparatus
    • • Metallurgical Mounting Press
    • • Magnetic Stirrer
    • • Hot Plate
    • • Vacuum Oven
    • • Weighing Balance
    • • Sonicator
    • • Hot Air Oven
    • • Hydraulic Press M-30 (Manual)
    • • Injection Moulding Machine (Semi-Automatic)

    These are updated equipments available in the lab to cater the knowledge of material properties.

    Advance Manufacturing Lab
    Equipments:

    • • 3D Printer 300X 300MM
    • • 3D Printer 600 X 600MM
    • • DLP 3D Printer CNC Milling
    • • CNC Lathe.

    Strength of Material Lab
    Equipments:

    • • Rheometer
    • • POD: Pin On Disk
    • • Scratch Tester
    • • Micro Vicker
    • • TMA: Thermal Mechanical Analysis.
    • • Strain Gauge
    • • S.S.BEAM (Simply Supported Beam)
    • • C.L.BEAM (Cantilever Beam)
    • • BUCKLING APPARATUS
    • • IMPACT TESTER
    • • FATIGUE TESTER
    • • SPRING STIFFNESS
    • • UTM (Universal Testing Machine

    Thermodynamic Lab
    Equipments:

    • • Heat Pump Test Rig Apparatus
    • • Vapour Compression Refrigeration Test Rig Apparatus
    • • Air Conditioning Test Rig Apparatus
    • • Cut Section Model Of Two Stroke Petrol Engine Apparatus
    • • Cut Section Model Of Four Stroke Diesel Engine Apparatus
    • • Two Stage Reciprocating Air Compressor Test Rig Apparatus
    • • Computerized Single Cylinder 4 Stroke Diesel Engine

    Fluid Mechanics Lab
    Equipments:

    • • Venturi meter & Orifice meter set-up (S.S Tanks) closed circuit
    • • Pipe Friction Apparatus (Major Losses)(S.S Tanks) Closed circuit
    • • Loss of Head in Pipe Fittings (Minor Losses) (S.S Tanks) Closed circuit
    • • Notch Apparatus (S.S Tanks) Closed circuit
    • • Buoyancy & Metacentric height setup (S.S Tanks) Closed circuit
    • • Free & forced vortex flow apparatus (S.S Tanks) Closed circuit
    • • Nozzle meter test rig (S.S Tanks) Closed circuit
    • • Verification of Bernoullis Apparatus & Reynoulds Apparatus
    • • Pitot Static Tube Apparatus

    Fluid Dynamic Lab
    Equipments:

    • • Orifice & Mouthpiece combined setup (S.S Tanks) Closed Circuit
    • • Impact of Jet on Vanes (S.S Tanks) Closed circuit
    • • Weirs Apparatus (S.S Tanks) Closed circuit
    • • Open Channel Apparatus (Hydraulic Flume)
    • • Hydraulic Bench
    • • Pelton Turbine
    • • Francis Turbine
    • • Centrifugal Pump
    • • Reciprocating Pump
    • • Gear oil Pump

    Manufacturing Processes Lab
    Equipments:

    • • High Temperature Furnace 1600°C
    • • Hot Extrusion Machine for Aluminium-110 Tonns.
    • • Stir Casting Machine
    • • Twin Screw Extruder
    • • 2HI/4HI Rolling Mill

    Theory of Machine Lab
    Equipments:

    • • Channel Vibration Analyser With Model Analysis With Model Hammer And Triaxle Accelerometer.
    • • Vibration Comprehensive Teaching kit.
    • • Computerized Universal Governor Apparatus
    • • Motorized Gyroscope
    • • Static & Dynamic Balancing Apparatus.
    • • Balancing of Reciprocating Masses Apparatus
    • • Whirling of shafts Demonstrator included
    • • Stroboscope
    • • Coriolis Component of Acceleration.
    • • Computerized Cam Analysis Machine without computer
    • • Optional Utility: Stroboscope
    • • Study & generation of involute tooth profile
    • • Study of basic 4 bar inversions
    • • Study of higher and lower order kinematic pair

    Electronics and Communication Engineering Labs

    These labs have equipment that transfers to the students the laboratory experience in basic electronic communications systems.

    Control System Lab
    Equipments:

    • • Digital Storage Oscilloscope( REGOL)
    • • PID Controller
    • • Control System Simulator
    • • DC Motor Speed Control
    • • Study of Stepper Motor
    • • Control System Lab
    • • NI ELVIS II + Hardware ( For Academic use only)
    • • Power cord ,250V,10A
    • • Quanser QNET 2.0 Dc Motor Board for NI ELVIS
    • • Quanser Qube-Servo 2.0 for Control Teaching with myRIO IO Connection
    • • NI myRIO -1900 University purchase Incl WIFI and MSP Connector
    • • Ni LabVIEW Professional Development Software
    • • UPS 20K
    • • ELVIS –III Connecting cables and probes
    • • Power cord ,250V,10A
    • • Quanser Mechatronics actuators board
    • • ELVIS-III Board Hardware
    • • NI Lab View Development Software

    Data Acquisition Lab
    Equipments:

    • • General Purpose DAQ Hardware NI USB 6008 Basic DAQ Hardware
    • • NI USB 6229M DAQ Hardware
    • • NI USB 6211 DAQ Hardware
    • • My DAQ Bundle (10Units) Hardware for Analog and Digital sensor interface
    • • My RIO Bundle (10Units) Hardware for Image Processing
    • • Robotics Hardware Bundle
    • • Biomedical Sensor acquisition bundle
    • • Compact RIO based autonomous
    • •Camera Processing Unit Vision Modules

    Digital Logic Design Lab
    Equipments

    • • Xilinx Vivado Suite-Latest(50 users)
    • • Digilent Zybo (Zynq-Z10) Board with Peripherals(35)
    • • Pmod 4 switches, Pmod 8LD
    • • ZED Devolpment board

    Digital Signal Processing Lab

    • • TMS320C6748 Development board along with software

    FEEE
    Equipments:

    • • Digital Storage Oscilloscope
    • • Regulated Power Supply
    • • Function Generators
    • • Digital Multimeters
    • • Multisim software National Instruments
    • • Rana Semi-Conductors-Consumables

    Microcontroller Lab
    Equipments:

    • • ESA KEIL MCB1760 Single Board Computer / Evaluation Board
    • • IF ESA KEIL MCB 1760 Interface Board
    • • Logical Controller Interface
    • • ESA KEIL MCB1760 Single Board Computer / Evaluation Board
    • • IF ESA KEIL MCB 1760 Interface Board
    • • Logical Controller Interface
    • • KEIL Software(50 users)
    • • KEIL Software(25 users)

    Software Packages:

    • • Multisim software National Instruments (30 users)
    • • Xilinx Vivado Suite latest make core EL Technologies (50 Users)
    • • Xilinx Vivado Suite latest make core EL Technologies(25 Users)
    • • Ni Lab View Professional Development Software (50 Users)

    Physics Lab


    Equipments:

    • • LASER experiment Set up, AE-458 (8nos.)
    • • Electrostatic Lab Trainer, NVIS-6202 (8nos.)
    • • Seebeck and Peltier Effect Unit, NVIS-6062 (8nos.)
    • • e/m Measurement set up – Thomson Experiment, NVIS-6103 (8nos.)
    • • Hall Effect Set up, HEX-25 (8nos.)
    • • Band gap measurement (Four Probe method), DFP-02 (8nos.)
    • • Photoelectric Effect Unit, PC-101 (8nos.)
    • • LCR Impedance measurement unit(8nos.)
    • • Gauss Meter, DGM-202 (1 no.)
    • • Ultra Sonic Cleaner (1 no.)
    • • Magnetic strrier,Digital Hot air overn (1 no.)
    • • Biot Savarts, Travelling Microscope, Digital Gauss Meter (8 nos.)
    • • Hysteresis Loop Tracer, Oscilloscope Optional, Dielectric Constant Measurement Setup (8 nos.)
    • • Solar Cell, Quink’s Tube Sample, (8 nos.) 0.1 mg Accuracy Micro Balance 220T, (1 no.)
    • • Chemistry Lab Setup at AB2 Room No.109

    Computer Science Labs

    We have five advanced computer labs and one computer center that are equipped with latest networking devices and advanced computers for students to learn, experience and create their own codes and programmes.

    • Desktops – lenovo (i5) and dell (i7)-(336 nos.)

    Various softwares such as Dev C++, Python, Matlab, R, OpenGL, Processing, Blender, Eclipse, Ubuntu, Rational Rose, Oracle etc are made available to students.
